H5 Cleveland Technology Center (CTC)

Login to Add Favorite Login to Request Pricing
Site: H5 Cleveland Technology Center (CTC)

Company: H5 Data Centers
Metro: Cleveland
State: Ohio
Country: United States
Region: North America
Region: Americas
Short Code: CTC
Address:
Total Building SqFt: 333,215
Gross SqFt: 64,000
Usable SqFt: 26,000
Total Power: 3.6 Megawatts

In January 2017, H5 acquired the building from ByteGrid.

Building:


  • Building Name: Cleveland Technology Center (CTC)
  • Utility Power Feeds: Dual path (2) diverse substations. 20MVA Utility feed
  • Parking: 120+ spaces
  • Number of Stories: Four (4)
  • Loading Docks: Two (2) Covered loading dock bays. No lift gate required.
  • Freight Elevator 15,000 lbs capacity

Phase 1:


  • Raised Floor Area: 30,000 ft2 in Phase 1 (expandable to 90,000 ft2)
  • Number of Computer Rooms: One (1)
  • Raised Floor Height: 30 in.
  • Raised Floor to Ceiling Height: 9.5 ft
  • Slab to Slab: 14 ft

Office Space:


  • Meeting Space: Two (2) conference rooms, plus shared hoteling space
  • Staging: Three (3) 400 SF Staging rooms
  • Burn-in: One (1) shared burn-in room
  • Office: Open dedicated office space available to lease
  • Storage: Open dedicated storage space available to lease

Power:


  • Description: Four (4) 2.4 MW Generators (each expansion phase)
  • Generator Redundancy: N+1
  • Storage Tanks: Two (2) 15,000 Gallons fuel tanks for 48hr runtime (each expansion phase)
  • PDU Description: 300kVA dual input MGE PDU

HVAC:


  • Description: Chilled Water System with air side economizer
  • Configuration: N+
  • Drycoolers: Leibert
  • Chillers: McQuay 400 T Chilled Water Units with VFD and pumps
  • CRAHs: Schneider Electric with 20% redundancy

Certifications:


  • SSAE16 SOC1 Type 2

Network Providers:


Armstrong, AT&T, Broadvox, CenturyLink, Cogent, FirstEnergy Fiber, OneCommunity, KDL, Level 3, Sting Communications, Time Warner Cable, Verizon, Windstream, Western Reserve Fiber, XO Communications and Zayo

June 2015 Expansion:


In 2015, ByteGrid commissioned 45,000 square feet of new data center space and 4 megawatts of power in a technology center in downtown Cleveland.

ByteGrid acquired the Cleveland Technology Center in 2013, following news it had secured a $100 million credit facility. The CTC is a 330,000-square-foot data center property sitting atop one of the larger fiber points of presence sites in Ohio. Acting as a carrier hotel in the region, the CTC was half leased at the time of acquisition. [Source: DCK]

Map and Nearby Locations:

1625 Rockwell Street, Cleveland, OH, 44114

SITES within 15 miles of H5 Cleveland Technology Center (CTC)

Show SqM



Distance Site name SqFt MW
0.06 miles SecureData 365 Cleveland 12,000
0.06 miles XO Cleveland
0.08 miles zColo Cleveland-1525 Rockwell 7,500
0.37 miles Fusion Connect Cleveland
0.37 miles Level3 Cleveland (1621 Euclid)
0.37 miles Cogent Cleveland 3,042
0.39 miles DataBank Cleveland CLE1 12,098 0.20
0.45 miles Level3 Cleveland (1228 Euclid)
0.72 miles vXchnge Cleveland 20,000 1.00
1.31 miles Lumen Cleveland (4000 Chester) 3,500 0.60
Lobby with a view of the conference room

CTC Circa 2013
CTC Circa 2017
Conference Room at H5 Cleveland
Source: H5
Lobby Area
Source: H5
Lobby with a view of the conference room
Lobby Area

Lobby with a view of the conference room

Source: H5
Entrance to 1625 Rockwell
Source: H5
Rooftop at CTC
Source: H5

December 2018

H5 CTC Data Sheet (PDF)
