Centrin: Wuhan Digital Valley

The Centrin Wuhan data center campus in central China occupies a 206,532.41-square-meter site, with planned building facilities totaling 500,000 square meters. The facility is being developed in two stages. The campus will accommodate up to 40,000 racks with capacity for 480,000 servers and maintains an annual average PUE below 1.4. The project has received Uptime Institute Tier-IV certification and is recognized as a major construction project by both Hubei province and Wuhan city.

• In 2022, Singaporean data center firm SpaceDC announced a partnership with Chinese operator Centrin Data to sell space in Wuhan data center.

Facility features

• Mega data center campus, covers an area of 206,532.41m2
• 3x 5-story and 4x 6-story buildings.
• Availability: 99.995%

Data hall features

• Up to 40,000 standard racks
• Support rack density range of 4-8kW per rack
• The average load in the equipment room is greater than 1200 kg/m2
• Rack size: 60012002320mm
• Floor to floor height of 5.9m

Utility power and generators

• Double power supply system
• A 110KV substation, dual mains
• Diesel generator N+ 1 redundancy, self-start within 60 seconds, oil storage for 12 hours

IT Power

• N + N dual UPS/HVDC

• 15 minutes backup time of a single battery

• 30 minutes backup time of the dual battery

Connectivity

• Multiple routing, 8 MMR per building
• Provides access to multiple ISP providers
• Telecom, unicom, mobile and other operators 3 route access
• Access other carriers based on customer requirements
• Supports bare fiber, BGP, SDH/MSTP, DDN, ATM, ISDN, and frame relay
